Advanced Fiber Optic Communication Trainer
Experiments Included:
Study an 820 nm fiber optic analog link
Frequency Modulation and Demodulation through Wired Medium
Frequency Modulation and Demodulation through Fiber Optic
Frequency Modulation and Demodulation of Voice Link through Fiber Optic
Amplitude Modulation and Amplitude Demodulation through Wired Medium
Amplitude Modulation and Demodulation through Fiber Optic
Amplitude Shift Keying Modulation and Demodulation through Wired Medium
Amplitude Shift Keying Modulation and Demodulation through Fiber Optic
Amplitude Shift Keying Modulation and Demodulation through Fiber Optic using PC
Frequency Shift Keying Modulation and Demodulation through Wired Medium
Frequency Shift Keying Modulation and Demodulation through Fiber Optic
Frequency Shift Keying Modulation and Demodulation through Fiber Optic using PC
Category: Telecommunication Technology Products
IT-4410 advanced fiber optic communication trainer provides the full understanding of the fiber optic communication. This trainer allows the student to perform experiments relating to digital and analog modulation/demodulation techniques and can study their transmission using wired medium and the transmission using optical fiber communication. PC-PC software is also provided with the trainer for transmission of PC data.
Features:
Power Supply Included
Required Circuits Tested
Each Section Clearly Marked for Input and Output
Each Section Works as an Independent Unit
Built-in Carrier Generator
Built-in Audio Generator
Built-in Data Generator
Built-In Clock Generators
Each Section Clearly Marked for Easy Understanding
Technical Features:
Transmitter: Fiber Optic LED
Receiver: Fiber Optic Photo detector (Pin Diode)
Carrier Generator: 300KHz
Modulation / Demodulation Techniques: AM, FM, ASK and FSK
Audio Generator: Variable Frequency and Amplitude
Data Generator: 8-bit DIP switch selectable
Clock Generator: 1KHz, 2KHz, 4KHz
Microphone Interface: for voice application
Drivers: Analog & Digital for Optical fiber
AC Amplifier: with variable gain
Low Pass Filter: 5th Order Butterworth, 3.4 KHz cut-off frequency
Audio Amplifier: Monolithic Amplifier with Speaker
Voice Link: F.O. voice link using microphone & speaker (built in)
PC-PC Communication: Using USB UART & software
Inter connections: 2 mm gold plated pin
Accessories: Power cord, Manual, Fiber Cable, Microphone, 2mm Patch Cords and Software CD, USB cables
