Digital Modulation Techniques Transmitter Trainer
Experiments Included:
Familiarization
ASK Modulation
FSK Modulation
BPSK Modulation
ASK, FSK, BPSK Modulation / De-modulation using PC
Category: Telecommunication Technology Products
Digital Baseband Data obtained through Sampling, PCM, PC or CVSD requires Modulation before it can be transmitted using Antennas. This trainer explores the basic Digital Modulation Techniques like FSK, ASK and BPSK. All components needed are provided on board. PC-PC link is established using USB-UART converter.
Features:
Power Supply Included
Required Circuits Tested
Each Section Clearly Marked for Input and Output
Each Section Works as an Independent Unit
Built-in Data Generator
Built-in Carrier Generator
Built-In Clock Generators
Each Section Clearly Marked for Easy Understanding
Technical Features:
Data generator: 8-Bit NRZ type
Modulation Types: ASK, FSK and BPSK
Carrier: 300KHz
PC interface: USB-UART interface
Interconnections: 2 mm gold plated pins
Accessories: Experiment Manual, 2mm patch cords and power cord, USB cable
