Filters and Oscillators Trainer
Experiments Included:
2nd Order Active Low Pass Filter
2nd Order Active High Pass Filter
2nd Order Active Band Pass Filter
2nd Order Active Band Reject Filter
Hartley Oscillator
Colpitts Oscillator
Colpitts Crystal Oscillator
Voltage Controlled Oscillator
Category: Telecommunication Technology Products
IT-4110 is designed to analyze & observe the techniques used for filters and oscillators. The trainer consists of different types of oscillators and filters. The trainer provides the full understanding of filter and oscillator circuits.
Features:
Power Supply Included
Required Circuits Tested
Each Section Clearly Marked for Input and Output
Each Section Works as an Independent Unit
Technical Features:
Low Pass Filter
High Pass Filer
Band Pass Filter
Band Reject Filter
Oscillator Types: Hartley, Colpitts, Colpitts crystal and Voltage Controlled
Interconnections: 2mm gold plated pins
Accessories: Experiment Manual, 2mm patch cords
